Mobile Diesel Construction Machinery Parts Concrete Mixer Truck From China
Concrete Mixer Truck From China
Mobile diesel construction machinery
Mixer truck for construction
Diesel mixer truck parts
Diesel construction machinery mixer
Concrete mixer truck parts
- Overview
- Product parameters
- Related Products
Overview
| Model | Tank capacity | Geometricalcapacity | Tank diameter | Hydraulic motor | Horsepower | Size | Weight |
| 1.5m³ | 1.5m³ | 2.5m³ | 1.4m | BMT30-125 | 28 | 4800*1600*2500mm | 1150kg |
| 2.5m³ | 2.5m³ | 3.6m³ | 1.6m | BMT30-125 | 32 | 5400*1950*2600mm | 1200kg |
| 3m³ | 3m³ | 5.2m³ | 1.8m | BMT30-125 | 65 | 6000*2100*2900mm | 1400kg |
| 4m³ | 4m³ | 6.1m³ | 1.8m | BMT30-160 | 75 | 6400*2200*3150mm | 1500kg |
| 5m³ | 5m³ | 8.5m³ | 2.05m | BMT50-250 | 140 | 7050*2300*3380mm | 2280kg |
| 6m³ | 6m³ | 9.9m³ | 2.05m | BMT50-250 | 140-160 | 7350*2350*3630mm | 2330kg |
| 7m³ | 7m³ | 11.2m³ | 2.15m | BMT50-250 | 160 | 7650*2400*3750mm | 2450kg |
| 8m³ | 8m³ | 12.2m³ | 2.2m | BMT50-400 | 180 | 8100*2400*3900mm | 2670kg |
| 9m³ | 9m³ | 13.2m³ | 2.3m | SUNNY-90 | 200 | 8570*2550*3895mm | 2980kg |
| 10m³ | 10m³ | 15m³ | 2.3m | SUNNY-90 | 220 | 8700*2500*3950mm | 3210kg |
